Share Charging team offers customized, end-to-end DC charging station solutions compliant with European standards.

Full-range DC fast charging stations from 40kW to 1.6MkW, supporting split-system architecture for high-traffic charging hubs.

NACS-Adapter

NACS-XX Charging Adapter Series

The CCS2-NACS charging adapter series is designed to improve compatibility between CCS1 charging infrastructure and NACS-equipped electric vehicles. With a compact structure, durable housing, and reliable electrical connection, this adapter series helps users access more charging options while supporting safe, stable, and efficient charging in different application scenarios.

NACS-CCS1 DC Adapter 1.0
Rated Current: 400A DC
Rated Voltage:1000VDC
Waterproof Grade: IP54
Plastic Shell: Thermoplastic Plastic
Conductor: Copperalloy, Silver Plated Surface
Working EnvironmentTemperature:-30°C~+50°C
Product Net Weight: 0.84kg
Product Size: 126.4*70.1*101.67mm
NACS-CCS1 DC Adapter V3-1
Rated Current: 400A DC
Rated Voltage: 1000VDC
Waterproof Grade: IP54
Plastic Shell: thermoplastic Plastic
Conductor: Copperalloy, Silver Plated Surface
Working Environment Temperature:-30°C~+50°C
Product Size: 126.4*70.1*101.67mm
NACS-CCS2 DC Adapter

Rated Current:250A DC
Rated Voltage:1000V DC
Waterproof Grade: IP54(after mating)
Plastic Shell: Thermoplastic Plastic
Conductor: Copperalloy, Silver Plated Surface
Working Environment Temperature:-30°C~+50°C
Product Net Weight: 1.06kg
Product Size:152.2*69.3*100.3mm

NACS-J1772 AC Adapter Without Lock 2.0
Rated Current: 80A Max
Rated Voltage: 250VAC Max
Waterproof Grade: IP54(after mating)
Plastic Shell:Thermoplastic Plastic
Conductor: Copperalloy, Silver Plated Surface
Working EnvironmentTemperature: -30°C~+50°C
Product Net Weight: 0.35kg
Product Size: 125.7*55*75.1mm
NACS-J1772 AC Adapter With Lock 1.0
Rated Current: 80A Max
Rated Voltage: 250VAC Max
Waterproof Grade: IP54(after mating)
Plastic Shell: Thermoplastic Plastic
Conductor: Copperalloy, Silver Plated Surface
Working Environment Temperature:-30°C~+50°C
Product Net Weight: 0.42kg
Product Size:127.7*55*77.21mm
NACS-CCS2 DC+AC Adapter
Rated Current: 250A DC/80A AC
Rated Voltage: 1000VAC/250VAC Max
Waterproof Grade: IP54(after mating)
Plastic Shell: Thermoplastic Plastic
Conductor: Copperalloy, Silver Plated Surface
Working Environment Temperature:-30°C~+50°C
Product Net Weight: 1.12kg
Product Size:152.2*69.3*100.3mm
NACS-GB/T AC Adapter
Rated Current: 80A Max
Rated Voltage: 250VAC Max
Waterproof Grade: IP54(after mating)
Plastic Shell:Thermoplastic Plastic
Conductor: Copperalloy, Silver Plated Surface
Working Environment Temperature: -30°C~+50°C
Product Net Weight: 0.33kg
Product Size: 113.2*56.09*70.93mm
NACS-TYPE 2 AC Adapter
Rated Current:32A
Rated Voltage: 250VAC max
Waterproof Grade:IP54(after mating)
Plastic Shell: Thermoplastic Plastic
Conductor: Copperalloy, Silver Plated Surface
Working Environment Temperature:-30°C~+50°C
Product Net Weight: 0.42kg
Product Size:222.37*69.5*87.38mm
NACS-GB/T DC Adapter
Rated Current: 300A Max
Rated Voltage: 1000V AC
Waterproof Grade: IP54(after mating)
Plastic Shell: Thermoplastic Plastic
Conductor: Copperalloy, Silver Plated Surface
Working Environment Temperature: -30°C~+50°C
Product Net Weight: 1.83kg
Product Size: 294.13*95.43*143.84mm
NACS V2L Adapter
Rated Current: 20A Max
Rated Voltage:125VAC Max
Waterproof Grade: IP54(After Mating)
Plastic Shell:Thermoplastic Plastic
Conductor: Copperalloy, Silver Plated Surface
Working Temperature: -30°C~+50°C
Product Net Weight: 0.35kg
Product Size: 140*58.6*69.8mm
