CCS1 to NACS/CCS2/GBT
/CHAdEMO Charging
Adapters
CCS2 to NACS, CCS1, GB/T, CHAdeMO and Type 2 adapters.
Explore nine adapter options for different charging interfaces.
NACS · CCS2 · GB/T · CHAdeMO
Model-dependent ratings
Silver-plated copper alloy
IP54 after mating
-30°C to +50°C
CCS1-NACS/CCS2/GBT /CHAdEMO Adapter Series
The CCS1-NACS charging adapter series is designed to improve compatibility between CCS1 charging infrastructure and NACS-equipped electric vehicles. With a compact structure, durable housing, and reliable electrical connection, this adapter series helps users access more charging options while supporting safe, stable, and efficient charging in different application scenarios. The series also includes CCS1-CCS2, CCS1-GB/T and CCS1-CHAdeMO models.
✓ Eight DC charging adapter models listed on the original product page
✓ NACS, CCS2, GB/T and CHAdeMO interface options
✓ Selected models combine DC and AC ratings
✓ Thermoplastic shells and silver-plated copper alloy conductors
✓ IP54 waterproof grade after mating; -30°C to +50°C operating temperature
8 Charging Adapter Models to Match Different Interfaces
CCS1-NACS DC Adapter (2.0)
- Rated Current: 300A DC
- Rated Voltage: 1000V DC
- Waterproof Grade: IP54 (after mating)
- Plastic Shell: Thermoplastic Plastic
- Conductor: Copper alloy, silver-plated surface
- Working Environment Temperature: -30°C to +50°C
- Product Net Weight: 0.71 kg
- Product Dimensions: 137.39 × 79.5 × 122.93 mm
CCS1-NACS DC Adapter (3.0)
- Rated Current: 300A DC
- Rated Voltage: 1000V DC
- Waterproof Grade: IP54 (after mating)
- Plastic Shell: Thermoplastic Plastic
- Conductor: Copper alloy, silver-plated surface
- Working Environment Temperature: -30°C to +50°C
- Product Net Weight: 0.71 kg
- Product Dimensions: 137.39 × 79.5 × 122.93 mm
CCS1-NACS DC+AC Adapter (3.0)
- Rated Current: 300A DC / 80A AC
- Rated Voltage: 1000V / 240V Max
- Waterproof Grade: IP54 (after mating)
- Plastic Shell: Thermoplastic Plastic
- Conductor: Copper alloy, silver-plated surface
- Working Environment Temperature: -30°C to +50°C
- Product Net Weight: 0.8 kg
- Product Dimensions: 137.39 × 79.5 × 122.93 mm
CCS1-NACS DC Cybertruck Adapter (4.0)
- Rated Current: 300A DC
- Rated Voltage: 1000V DC
- Waterproof Grade: IP54 (after mating)
- Plastic Shell: Thermoplastic Plastic
- Conductor: Copper alloy, silver-plated surface
- Working Environment Temperature: -30°C to +50°C
- Product Net Weight: 1.055 kg
- Product Dimensions: 159.6 × 85.09 × 123.32 mm
CCS1-NACS DC+AC Cybertruck Adapter (4.0)
- Rated Current: 30A DC / 80A AC
- Rated Voltage: 100V DC / 240V AC Max
- Waterproof Grade: IP54 (after mating)
- Plastic Shell: Thermoplastic Plastic
- Conductor: Copper alloy, silver-plated surface
- Working Environment Temperature: -30°C to +50°C
- Product Net Weight: 0.88 kg
- Product Dimensions: 137.39 × 79.5 × 122.93 mm
CCS1-CCS2 DC+AC Adapter
- Rated Current: 250A DC / 63A AC
- Rated Voltage: 1000V DC / 250V AC Max
- Waterproof Grade: IP54 (after mating)
- Plastic Shell: Thermoplastic Plastic
- Conductor: Copper alloy, silver-plated surface
- Working Environment Temperature: -30°C to +50°C
- Product Net Weight: 0.78 kg
- Product Dimensions: 112.9 × 69.6 × 100.22 mm
CCS1-GB/T DC Adapter
- Rated Current: 250A Max
- Rated Voltage: 1000V DC Max
- Waterproof Grade: IP54 (after mating)
- Plastic Shell: Thermoplastic Plastic
- Conductor: Copper alloy, silver-plated surface
- Working Environment Temperature: -30°C to +50°C
- Product Net Weight: 1.44 kg
- Product Dimensions: 282.18 × 95.48 × 143.81 mm
CCS1-CHAdeMO DC Adapter
- Rated Current: 250A Max
- Rated Voltage: 1000V DC Max
- Waterproof Grade: IP54 (after mating)
- Plastic Shell: Thermoplastic Plastic
- Conductor: Copper alloy, silver-plated surface
- Working Environment Temperature: -30°C to +50°C
- Product Net Weight: 1.84 kg
- Product Dimensions: 89 × 95.37 × 150.85 mm
Compare All 8 Adapter Models
Model
CCS1-NACS DC (2.0)
CCS1-NACS DC (3.0)
CCS1-NACS DC+AC (3.0)
NACS DC Cybertruck (4.0)
NACS DC+AC Cybertruck (4.0)
CCS1-CCS2 DC+AC
CCS1-GB/T DC
CCS1-CHAdeMO DC
Rated Current
300A DC
300A DC
300A DC / 80A AC
300A DC
30A DC / 80A AC
250A DC / 63A AC
250A Max
250A Max
Rated Voltage
1000V DC
1000V DC
1000V / 240V Max
1000V DC
100V DC / 240V AC Max
1000V DC / 250V AC Max
1000V DC Max
1000V DC Max
Waterproof Grade
IP54 (after mating)
IP54 (after mating)
IP54 (after mating)
IP54 (after mating)
IP54 (after mating)
IP54 (after mating)
IP54 (after mating)
IP54 (after mating)
Plastic Shell
Thermoplastic plastic
Thermoplastic plastic
Thermoplastic plastic
Thermoplastic plastic
Thermoplastic plastic
Thermoplastic plastic
Thermoplastic plastic
Thermoplastic plastic
Conductor
Copper alloy, silver-plated surface
Copper alloy, silver-plated surface
Copper alloy, silver-plated surface
Copper alloy, silver-plated surface
Copper alloy, silver-plated surface
Copper alloy, silver-plated surface
Copper alloy, silver-plated surface
Copper alloy, silver-plated surface
Working Temperature
-30°C to +50°C
-30°C to +50°C
-30°C to +50°C
-30°C to +50°C
-30°C to +50°C
-30°C to +50°C
-30°C to +50°C
-30°C to +50°C
Net Weight
0.71 kg
0.71 kg
0.8 kg
1.055 kg
0.88 kg
0.78 kg
1.44 kg
1.84 kg
Product Dimensions
137.39 × 79.5 × 122.93 mm
137.39 × 79.5 × 122.93 mm
137.39 × 79.5 × 122.93 mm
159.6 × 85.09 × 123.32 mm
137.39 × 79.5 × 122.93 mm
112.9 × 69.6 × 100.22 mm
282.18 × 95.48 × 143.81 mm
89 × 95.37 × 150.85 mm
Suitable for Various Charging Scenarios
Tesla / NACS Vehicles
Public Charging Stations
Fleet & Commercial Use
Cross-Standard Compatibility
Custom Charging Adapter Solutions
Frequently Asked Questions
Adapter configurations are available for NACS, CCS1, CCS2, GB/T and CHAdeMO. Actual compatibility depends on the specific adapter model and the vehicle and charger interfaces.
Selected models support both DC and AC charging; other models are designed for DC only. Please check the exact model specification before ordering.
The products use thermoplastic housings and copper alloy contacts with a silver-plated surface, according to the product specifications. Match electrical ratings to your vehicle and charging equipment.
IP54 indicates protection against limited dust ingress and water splashes under the applicable test conditions. Product specifications state IP54 after mating.
Yes. Contact us to discuss OEM/ODM project requirements, adapter configuration and branding options.
Typical applications include compatible EV charging at homes, public charging stations, commercial fleets and cross-standard charging infrastructure.
